tbqm-type gas turbine flowmeter
it is a high-precision gas flow metering instrumentst that has been widely used in gas fiscal metering .tbqm-type gas turbine flowmeter is our new generation ce approved mechanical turbine flowmeter for accurate gas flow measurement. the product is designed for nominal pressure ratings from 1.6mpa to 16mpa (≥dn200 is 10mpa). the product can be configured with volume corrector or flow computer to convert to volumetric or energy metering at reference conditions and transfer the flowmeter measurement parameters to the data center based on the function of volume corrector.
the main performance of the product has reached the international advanced level. it is considered as an ideal instrument for the measurement and detection of natural gas and other gases for the petroleum, chemical industry, power, metallurgy as well as city gas industries.
main functions
configuring with volume corrector to achieve the following function:
● configured with fcm-type volume corrector, to have the correction of temperature, pressure and compressibility factor and convert volume at measurement condition into volume at reference condition;
● configured with tfc-type volume corrector, it could additionally transfer the data on site to the data center via gprs/cdma;
● configured with fcc-type flow compensation controller, it can achieve prepayment function.
key technologies
in-built high pressure lubrication system, axial shock resistance, universal index, non -magnetic detection for high pressure high frequency turbine blade ,exchangeable metering cartridge,dust-free chamber, magnetic shielded counter
authentication
● production license (including type approval and atex and iecex)
● eu measuring instruments directive (mid) (module b d, ce-203)
● pressure equipment directive(ped) 2014/68/eu
● international organization of legal metrology (oiml) :r137-1:2012 certification (r137/2012-nl1-15.08)
patent
patent no.(zl201430056734.2): gas turbine flowmeter(tbqm)
patent no.(zl20160528791.x): a shock-resistant turbine flowmeter
patent no.(zl201420094419.3): universal counting flowmeter
technical specifications
